V155-3.6 MW™

With the introduction of V155-3.6 MW™, Vestas expands the 4 MW platform to strengthen park performance in low and ultra-low wind conditions.

V155-3.6 MW™ at a glance

With the introduction of V155-3.6 MW™, Vestas expands the 4 MW platform to strengthen park performance in low and ultra-low wind conditions. V155-3.6 MW™ features the largest rotor of the 4 MW platform, increasing swept area to 18 869m2 and delivering excellent partial load energy production.

 Combined with a 3.6MW standard rating, V155-3.6 MW delivers comparable park AEP with 39% fewer turbines for MW-constrained markets.

Options
available for the

V155-3.6 MW™ IEC S

  • Condition Monitoring System
  • Service Personnel Lift
  • Vestas Ice Detection
  • Low Temperature Operation to -30°C
  • Fire Suppression
  • Shadow Detection
  • Vestas Bat Protection System
  • Aviation Lights
  • Aviation Markings on the Blades

4 MW

The Vestas 4 MW platform sets new standards for onshore wind performance within regimes ranging from very strong wind and typhoon conditions to low wind.

IEC S

The V155-3.6 MW™ IEC S is designed for low and ultra-low wind sites.

+47 GW

The performance and versatility of the 4 MW platform has been proven with more than 47 GW installed in 57 countries since 2010.

Technical specifications

Power regulation operational data
Pitch regulated with variable speed
Rated power
3,600kW
Cut-in wind speed
3m/s
Cut-out wind speed
18m/s
Re cut-in wind speed
16m/s
Wind class
IEC S
Standard operating temperature range
from -20°C* to +45°C with de-rating above 30°C

SOUND POWER
Maximum
108.8dB(A) Sound Optimised modes dependent on site and country

ROTOR
Rotor diameter
155m
Swept area
18,869m2
Aerodynamic brake
full blade feathering with 3 pitch cylinders

ELECTRICAL
Frequency
50/60 Hz
Converter
full scale

GEARBOX
Type
two planetary stages and one helical stage

TOWER
Hub heights
Site and country specific

HUB DIMENSIONS
Max. transport height
3.8m
Max. transport width
3.8m
Max. transport length
5.5m

BLADE DIMENSIONS
Length
76.2m
Max. chord
4.2m
Max. weight per unit for transportation
70 metric tonnes

AEP Curve

4 MW Platform

Our 4 MW platform is designed for a broad range of wind and site conditions, onshore and offshore enabling you to mix turbines across your site or portfolio of sites, delivering industry-leading reliability, serviceability and exceptional energy capture.

The 4 MW platform was introduced in 2010 with the launch of the V112-3.0 MW®. Over 51 GW of the 4 MW platform has been installed all over the world onshore and offshore making it the obvious choice for customers looking for highly flexible and trustworthy turbines.

Rotor diameters range from 105 to 155 meters and the rated output power is up to 4.5 MW. Using well proven technologies like a full-scale converter, the 4 MW platform meets even the most challenging grid requirements providing excellent energy yield in all wind and weather conditions.

Large Diameter Steel Towers (LDST) are also available to optimise annual energy production on low wind sites.

The 4 MW platform combines Vestas’ proven track record with our continuous efforts to improve and optimise our products, making it the obvious choice for customers looking to combine reliability with performance.
